Will the Eberspacher M3 B4L gasoline heater fit under a ford transit passenger seat with a swivel? thank you very much

Question

Will the Eberspacher M3 B4L gasoline heater fit under a ford transit passenger seat with a swivel? thank you very much

This question is related to Eberspacher Espar Airtronic M3 B4L Ford Transit Gasoline Heater Kit inc Easy Start Pro 4kw 12v.

View product

Answers (1)

Answered by Butler Technik's David Butler
Posted 6th March, 2026 at 15:23 by David Butler

I think this larger 4kw Eberspacher heater might be a tight fit - I would suggest you please take a look at the attached image from install manual for required dimensions, then compare with the available space - also please find a useful link to the full instal manual which discusses all required install parameters

https://www.butlertechnik.com/downloads/cms/eberspacher-espar-airtronic-m3-d4l-b4l-technical-installation-manual.pdf

Attachments:

Click on an attachment to open in a new window.
