Can i use one 25 amp fuse to connect the Eberspacher S3 wiring to DC power? Instead of the the 2 circuit with one 5 amp fuse and one 20 amp fuse? I want to combine the 2 positive wires on the wiring harness and remove the in line fuses. Then I can connect to one 25 amp fuse on my fuse block.

Part #  HS3CAMPERKIT12VG

Thanks



Question

Can i use one 25 amp fuse to connect the Eberspacher S3 wiring to DC power? Instead of the the 2 circuit with one 5 amp fuse and one 20 amp fuse? I want to combine the 2 positive wires on the wiring harness and remove the in line fuses. Then I can connect to one 25 amp fuse on my fuse block.    Part #  HS3CAMPERKIT12VG  Thanks

This question is related to Eberspacher Espar Petrol Gasoline Heater Camper Kit for Air and Water Heating Hydronic S3 B5E 5kW 12v.

View product

Answers (1)

Answered by Butler Technik's David Butler
Posted 22nd April, 2025 at 10:22 by David Butler

Good Question.However, the fused circuit modification you suggest should NOT be undertaken.

Reason - you will negate the recommended fuse rating for all the wiring and components that they relate to.

The 20A fuse is required to correctly protect the higher current (ampere) consuming heater unit ie, the heater internal combustion motor, glowpin and larger cross section cables powering the heater.

The 5A fuse is lower rated to protect the heater controller and small cross section cables utilised in that circuit.

Please keep these two fused circuits separated as shown in the electrical circuit diagram attached.

Any further questions, please call 01522 243310 or email sales@butlertechnik.com

Thank you
